| Material |
Steel |
ZDC-2 |
| Working
Pressure | 15
kgf/cm2 | 10
kgf/cm2 |
| Maximum
Pressure | 20
kgf/cm2 | 15
kgf/cm2 |
| Temp.
Range | -20°C~+80°C | |
| Size |
1/4"
(20 type) | |
| 3/8"
(30 type) | ||
| 1/2"
(40 type) | ||
| Applications |
| *Pneumatic tools |
| *Air piping |
| *Air pressure equipment |
| *Water piping |
| *Improved operation. Constructed for one-touch connection by simply pushing the plug into the socket. |
| *Chrome plated steel body for anti-corosion. Gives long term, stable functioning. |
| *Widely confirured with male and female thread connections, hose connectors, manifolds, to suit wide |
| variety of piping applications for pneumatic appliances. |
| 20SHA |
5/16"(HOSE) |
 |
 |
20PHA |
5/16"(HOSE) |
| 30SHA |
3/8"(HOSE) |
30PHA |
3/8"(HOSE) | ||
| 40SHA |
1/2"(HOSE) |
40PHA |
1/2"(HOSE) | ||
| 20SFA |
1/4"(PT) |
 |
 |
20PFA |
1/4"(PT) |
| 30SFA |
3/8"(PT) |
30PFA |
3/8"(PT) | ||
| 40SFA |
1/2"(PT) |
40PFA |
1/2"(PT) | ||
| 20SMA |
1/4"(PT) |
 |
 |
20PMA |
1/4"(PT) |
| 30SMA |
3/8"(PT) |
30PMA |
3/8"(PT) | ||
| 40SMA |
1/2"(PT) |
40PMA |
1/2"(PT) | ||
| 20SPA |
5 x 8MM |
 |
 |
20PPA |
5 x 8MM |
| 30SPA |
6.5 x 10MM |
30PPA |
6.5 x 10MM | ||
| 40SPA |
8 x 12MM |
40PPA |
8 x 12MM |
©
