| Description
/ Type |
FRL502 |
FRL503 |
FRL504 |
| Port
Size (PT, NPT) | 1/4" |
3/8" |
1/2" |
| Filter
Element | 5u |
| Adj.
Pressure Range | 0.5~10.2kgf/cm2 |
| Max
Service Pressure |
15kgf/cm2 |
| Max
Flow (1/min) | 2200 |
3000 |
3100 |
| Operating
Temp Range | 5~60°C |
| Drain
Capacity | 55ml |
| Oil
Capacity | 80ml |
| Recommendable
Lubricants | ISO
VG-32 | | Type
of Constitution Unit |
Filter/Regulator |
FR502 |
FR503 |
FR504 |
| Lubricator |
L502 |
L503 |
L504 |
| |
|
